The largest manufacturer of ATS in ChinaHigh quality standard enterprise supplier,Nader,GE, Siemens supplierQuickly lead times:Both of us ”Time is gold” ,7*20 hours online serviceProfessional team,Research and development, design, productionLead Time:
Customization:
| Quantity(Pieces) | 1 - 100 | >100 |
| Est. Time(days) | 7 | To be negotiated |
Customized logo(Min. Order: 100 Pieces)
Customized packaging(Min. Order: 100 Pieces)
Graphic customization(Min. Order: 100 Pieces)
Product detail
Model | YES1-32NA | YES1-125NA | |||||
Rated current(A) | 16,20,25,32 | 40,50,63,80,100,125 | |||||
Rated control current(A) | 5 | ||||||
Rated short time current(kA) | 10 | ||||||
The rated impulse withstand voltage(kV) | 8 | ||||||
Service | Mechanical | 20000 | |||||
Electric | 6000 | ||||||
Pole | 2P | 3P | 4P | 2P | 3P | 4P | |
Weight(kg) | 4.2 | 4.7 | 5.2 | 5 | 5.5 | 6.5 | |
Operating cycle(s/time) | 10 | ||||||
| Name | Content |
| Enterprise code | Shanghai Yuhuang electric co.,ltd |
| Product category | PC class Automatic Transfer Switch |
| Design code | 1 |
| Current rank | NA/N/C:32A,125A,250A,400A,630ASA/S/LA/L:125A,250A,630AG:100A,250A,630A,1600A,3200AM:1600A AQ:3200A |
| Product code | NA:16A~630A(Integral type,two positions)N:16A~630A(Split type,two positions)C:16A~630A(Split type,two positions)M:630A~1600A(Split type,two positions)Q:630A~3200A(Split type,two positions)SA:20A~630A(Integral type,Three positions)S:20A~630A( Split type,Three positions)LA:20A~630A(Integral type,Two positions)L:20A~630A(Split type,two positions)G:GA:16A~3200A(With fire protection function)GA1:16A~100A(Without fire protection function) |
| Pole | 2P(125A and below 125A products),3P,4P |
| Rated current | 16A~3200A |
| Working mode | R=Self-input and self-recoverS=Self-input without self-recoverF=Utility-Generator |
